Boeing C-5 Design Concept

Although Boeing lost the competition for the gigantic military transport, the C-5A, Boeing took advantage of the high bypass engine technology developed for the C-5A to develop the new gigantic 747 commercial transport. The design philosophy behind the 747 was to develop a completely new plane, and other than the engines, the designers purposefully avoided using any hardware developed for the C-5.
 Add to lightbox
 Add to cart
Unique identifier BI630071
Boeing ID ce11386
Type Image
Size 1879px × 1386px   7MB
License type RM
Restrictions
