Inside the Mock-up of Boeing's C-5 Concept

In the 1960s, Boeing competed with other aerospace companies to win the U.S. Army's Request for Proposal for a new large military transport, the CX-HLS, or Cargo Experimental-Heavy Logistics System. Boeing was one of three companies whose proposal was selected for further study. Although Boeing's design did not win the competition, Boeing then set out to out to develop a large advanced commercial airplane to take advantage of the high bypass engine technology developed for the C-5A, the 747.
 Add to lightbox
 Add to cart
Unique identifier BI230729
Boeing ID p37534
Type Image
Size 1850px × 1448px   2MB
License type RM
Keywords
1960s
adults
airplanes
business executives
businesspeople
C-5A Galaxy
candids
cargo holds
Conceptual aircraft, designed, but never produced
glare
ground shots
historic production status
inspecting
interiors
jets
large
male
military
military personnel
monoplanes
payload systems
perspective lines
photos
several/groups
standing
transports
