DC-X Aeroshell is Lowered over Hydrogen Tank and Thrust Structure

Under a cooperative agreement with NASA, McDonnell Douglas integrated advanced technology components into the vertical-takeoff, vertical-landing DC-X rocket. The components included a McDonnell Douglas-built advanced composite liquid hydrogen tank and a Russian-built aluminum-lithium liquid oxygen tank. In addition, the cone-shaped vehicle utilized an advanced composite fuel feedline, fuel valve and an advanced composite intertank structure which connected the two tanks.
 Add to lightbox
 Add to cart
Unique identifier BI629647
Boeing ID dcx_as22
Type Image
Size 992px × 1419px   4MB
License type RM
Restrictions
