Joint Direct Attack Munition Extended Range Illustration
On March 31, 2009 Boeing announced an agreement with Times Aerospace Korea, LLC (TAK) to jointly develop a wing assembly for the 2,000-pound Joint Direct Attack Munition Extended Range (JDAM ER). Under the teaming arrangement signed Feb. 27, Boeing and TAK will co-develop, test, and field a JDAM ER wing kit to convert the 2,000-pound JDAM into a JDAM ER. Over the course of the 40-month development program, Boeing will provide support to TAK as the Korean company further develops its aerospace capabilities, including preparations for production of the JDAM ER wing assembly. Upon successful completion of the development and flight-test programs, TAK will become Boeing's primary supplier for the 2,000-pound JDAM ER wing assembly. JDAM is a low-cost guidance kit that converts existing unguided free-fall bombs into accurately guided "smart" weapons. The JDAM kit consists of a tail section that contains a Global Positioning System/Inertial Navigation System and body strakes for additional stability and lift. The incorporation of the Extended Range wing kit extends JDAM's standoff range.
