Joint Direct Attack Munition (JDAM) in Flight
The Joint Direct Attack Munition (JDAM) guidance kit is a low-cost guidance kit that converts existing unguided free-fall bombs into accurately guided "smart" weapons. The JDAM kit consists of a tail section that contains a Global Positioning System/Inertial Navigation System and body strakes for additional stability and lift. Since 1998, Boeing has produced more than 150,000 JDAM tail kits.
Add to lightbox
Add to cart
Unique identifier
BI218602
Boeing ID
d4c-122657-1
Size
2670px × 3300px 25MB
