JDAM on Transport
The Joint Direct Attack Munition (JDAM) is a guidance kit that converts existing unguided free-fall bombs into precision-guided smart munitions. By adding a new tail section containing a global positioning system (GPS)/inertial navigation system (INS) guidance control unit to existing inventories of Mk-83 and BLU-110 1,000-pound bombs, and the Mk-84 and BLU-109 2,000-pound bombs, the cost-effective JDAM will dramatically improve the accuracy of precision strike munitions in adverse weather. JDAM can be dropped by an aircraft from up to 15 miles from the target. Updates from GPS satellites will help guide the bomb to the target.
Add to lightbox
Add to cart
Unique identifier
BI28356
Boeing ID
88sk03462
Type
Size
3000px × 2400px 20MB
License type
RM
Keywords
1990s
ammunition/weapons systems
currently in production
full body views
ground shots
interiors
left front views
military
nobody
photos
scanned from film negative
white
