Dyna-Soar Transtage Separation

In the late 1950s, Boeing engineers used rocket-based technology to design the Dyna-Soar, a manned, reusable space vehicle that would glide through the Earth's upper atmosphere after being lifted into orbit by a rocket. Dyna-Soar reached the mock-up stage before the project was canceled in 1963, before the prototype was built. Many aspects of the delta-winged space vehicle were similar to the space shuttles that orbited the Earth some 30 years later.
 Add to lightbox
 Add to cart
Unique identifier BI22014
Boeing ID bw175188
Type Image
Size 4798px × 5998px   27MB
