Dual Propeller Installation for XF8B-1

The XF8B-1 fighter-bomber was the heaviest carrier-based airplane built before the end of World War II. It was the first fighter Boeing built after the P-26 Peashooter of 1936 and the last before the F/A-22 in 1990. The XF8B-1 could be flown as a torpedo bomber and, because of its single-seat configuration, could also be used as a fighter. Because of its size and great horsepower, the XF8B-1 used an unusual dual six-blade contrarotating propeller. It carried bombs internally and extra fuel externally, and its six machine guns were mounted inside the folding wings.
 Add to lightbox
 Add to cart
Unique identifier BI219822
Boeing ID 82983b
Type Image
Size 5100px × 3950px   19MB
License type RM
Keywords
1940s
airplanes
close-ups
detail views
engines
factories
fighter/attack
glare
ground shots
historic production status
interiors
manufacturing
military
monoplanes
nobody
photos
propeller planes
propellers
prototypes
text
viewed from below
Restrictions
