5.5-meter Composite Cryogenic Tank
The 5.5-meter tank currently is being manufactured at the Boeing Developmental Center in Tukwila, Wash. It will be one of the largest composite propellant tanks ever made and is scheduled to be pressure-tested in 2014 at NASA's Marshall Space Flight Center in Huntsville, Ala. John Vickers, the cryogenic tank project manager at Marshall said "The 18-foot (5.5-meter) tank will be one of the largest composite propellant tanks ever built and will incorporate design features and manufacturing processes applicable to a 27.5-foot (8.4-meter) tank, the size of metal tanks found in today's large launch vehicles."
Add to lightbox
Add to cart
Unique identifier
BI41302
Boeing ID
Cryotank-2
Type
Size
4000px × 3000px 34MB
License type
RM
Keywords
composites
cryogenic tanks
robots
