5.5-meter Composite Cryogenic Tank

The 5.5-meter tank currently is being manufactured at the Boeing Developmental Center in Tukwila, Wash. It will be one of the largest composite propellant tanks ever made and is scheduled to be pressure-tested in 2014 at NASA's Marshall Space Flight Center in Huntsville, Ala. John Vickers, the cryogenic tank project manager at Marshall said "The 18-foot (5.5-meter) tank will be one of the largest composite propellant tanks ever built and will incorporate design features and manufacturing processes applicable to a 27.5-foot (8.4-meter) tank, the size of metal tanks found in today's large launch vehicles."
 Add to lightbox
 Add to cart
Unique identifier BI41302
Boeing ID Cryotank-2
Type Image
Size 4000px × 3000px   34MB
License type RM
Keywords
composites
cryogenic tanks
robots
