General Arrangement BOEING 747 F Freighter

"BOEING 747 F Freighter." Brochure D6-13920 R1, 78 pages (printed one side only), issued June 1969 by the Commercial Airplane Division, Everett [Washington] Branch of The Boeing Company; page 6 "GENERAL ARRANGEMENT," three-view drawing with basic dimensions for Boeing Model 747-100F series aircraft. [Page 6 of 78.]

1969
 Add to lightbox
 Add to cart
Unique identifier BI429234
Boeing ID D6-13920R1_6-1969_pg6_747F_General_Arrangement
Type Image
Size 3217px × 2545px   6MB
