Boeing Transonic Truss-Braced Wing Concept
Boeing’s Transonic Truss-Braced Wing concept has real potential as a next-generation, ultra fuel-efficient aircraft.
NASA recently awarded Boeing a risk-reduction contract for ultra-efficient subsonic transport research.
The contract spans both the Blended Wing Body and Transonic Truss-braced Wing vehicle concepts developed by Boeing Research & Technology.
The contracts will continue research of key technologies that will bring both concepts closer to a flight demonstrator.
