Boeing 767-400ER in Wind Tunnel Testing

June 26, 1997 - Inside the Boeing Transonic Wind Tunnel in Seattle, WA, an engineer takes readings from the 767-400ER (extended range) airplane model. In the final series of high-speed wind tunnel tests, Boeing evaluated wing extensions, winglets and raked tips, all of which increase the 767-400ER wing span. The tests proved that the highly swept, 8-foot raked tips gave the best overall configuration for improved airplane takeoff performance and better range and fuel burn. A model configured for low-speed analysis will complete testing this month in the Defense Evaluation and Research Agency (DERA) wind tunnel facility in Farnborough, England.
 Add to lightbox
 Add to cart
Unique identifier BI227971
Boeing ID r1yh
Type Image
Size 2935px × 2345px   19MB
License type RM
