787 Dreamliner Model in Tests at Boeing's Transonic Wind Tunnel

Dale Belter, data engineer, and Kevin Schoenen, test director, prepare the Boeing 787 Dreamliner model for a series of tests at the Boeing transonic wind tunnel facility in Seattle on May 26, 2004. The tests helped to verify the performance of the airplane design during the highest-speed portions of flight. The 787 will cruise at Mach 0.85, the fastest cruise speed for any large commercial jet.
