Vibration Testing Boeing Tracking and Data Relay Satellite- K

The next-generation series of Boeing Tracking and Data Relay Satellites (TDRS) will increase NASA’s signal processing and transmission capabilities among the Hubble Space Telescope, the International Space Station and dozens of unmanned scientific satellites in low Earth orbit. TDRS K, the first to offer that increase in operational effectiveness, completed all environmental, functional and performance tests, including vibration and acoustic tests and final flight functional testing in October 2012. TDRS L and M are also in production. Boeing built the TDRS H, I and J satellites that are currently in operation.
 Add to lightbox
 Add to cart
Unique identifier BI233306
Boeing ID sef12-08165-001
Type Image
Size 2400px × 3000px   20MB
License type RM
Keywords
2010s
bright
complexity
copy space
factories
full body views
gray
ground shots
high-tech / advanced
interiors
photos
solar panels
testing
white
