Boeing Icon II Concept Aircraft
Two teams led by Boeing Research & Technology completed 18-month studies and submitted their findings to NASA under a program called N+3, which denotes three generations beyond the current transport fleet. The Boeing supersonic team, which includes BR&T, BCA, Pratt & Whitney, Rolls Royce, General Electric, Georgia Tech, Wyle and M4 Engineering, has recommended to NASA a fixed wing configuration (nicknamed Icon II) with V-tails and upper surface engines as the technology reference concept plane for N+3. The Icon II concept can carry 120 passengers in a two-class, single-aisle interior, and can cruise at Mach 1.6 to Mach 1.8 with a range of about 5,000 nautical miles.
Add to lightbox
Add to cart
Unique identifier
BI231951
Boeing ID
iconii_r6
Type
Size
5100px × 2777px 40MB
License type
RM
Keywords
2010s
aerial views
airplanes
blue
clouds
commercial
commercial passenger planes
Conceptual aircraft, designed, but never produced
copy space
day
exteriors
flying
full body views
fuselages
high-tech / advanced
illustrations
jets
monoplanes
NASA N+3 Program
nobody
oceans
right front views
structural systems
sunshine
tails
viewed from above
white
