F-15SE Silent Eagle Port Weapons Bay and Landing Gear
On March 17, 2009, Boeing introduced its newest F-15, the F-15 Silent Eagle. Changes to the F-15 include canted vertical tails, coatings and treatments on the aircraft, and internal weapons carriage. One of the most innovative changes comes in the form of internal weapons carriage capability. The Silent Eagle will carry aerodynamic Conformal Fuel Tanks that have been modified for internal weapons carriage. The internal carriage capability minimizes radar signature and significantly increases pilot tactical options in combat. Each modified CFT (left hand and right hand) will be equipped with two internal bays designed for multiple carriage configurations, including air-to-air and air-to-surface weapons. The CFTs also can be used to carry avionics packages such as broadband jamming equipment for stand-off jamming missions, or side-looking radars or reconnaissance equipment.
