Apollo CSM Assembly Diagram

All the major sections of the Apollo spacecraft and launch vehicle, with the exception of the Grumman-built Lunar Module, were developed and built by companies that would later join to form 21st century Boeing. These companies had a common customer, NASA, which led the U.S. effort to put a man on the Moon and return him safely to Earth. The Apollo command and service modules were built at North American Aviation's plant at Downey, California.
 Add to lightbox
 Add to cart
Unique identifier BI230509
Boeing ID ap27
Type Image
Size 3950px × 5100px   57MB
License type RM
Keywords
1960s
Apollo Program
complexity
cutaway views
diagrams
full body views
high-tech / advanced
historic production status
illustrations
nobody
POINT OF VIEW
space
spacecraft
text
