Apollo Command Module Drop Test at the Impact Test Facility

The Apollo command and service modules were built at North American Aviation's plant at Downey, California. The lunar lander, in the eyes of some observers, was the most critical part of the Apollo vehicle. The many things that could doom the crew made ground-testing all the more important, so the company built a 150-foot-high Impact Test Facility. It looked like a gigantic playground swing and checked the module's structural integrity and impact loads by drop-testing it on water (shown here), sand, gravel and boulders.
 Add to lightbox
 Add to cart
Unique identifier BI230535
Boeing ID ap38
Type Image
Size 4050px × 5100px   59MB
License type RM
