Early Design Study for X-48B Blended Wing Body (BWB)

Two high-fidelity, 21-foot wingspan prototypes of the BWB concept were designed and produced for wind tunnel and flight testing in 2006. The Air Force designated the vehicles as the "X-48B," based on its interest in the design's potential as a flexible, long-range, high-capacity military aircraft. The Blended Wing Body relies solely on multiple control surfaces on the wing for stability and control.
 Add to lightbox
 Add to cart
Unique identifier BI218838
Boeing ID x-48bbwb
Type Image
Size 3000px × 2400px   20MB
License type RM
