Multifunction Electronic Display Subsystem (MEDS)
HONEYWELL ARTIST'S RENDERING of the Multifunction Electronic Display Subsystem, which will replace cathode ray tube screens, mechanical gauges and instruments in America's Space Shuttle cockpits with full-color, flat-panel displays like those on modern commercial andmilitary aircraft. MEDS will reduce Shuttle maintenance costs, help avoid obsolescence issues,reduce vehicle weight and power consumption, improve Shuttle reliability and performance and iscapable of expansion. Atlantis will be the first orbiter to receive MEDS during its maintenance period at the Boeing Palmdale, Calif. facility now through August 1998.
Add to lightbox
Add to cart
Unique identifier
BI213902
Boeing ID
s1k1h
Type
Size
1800px × 1412px 7MB
License type
RM
Keywords
1980s
black
close-ups
flight decks
high-tech / advanced
illustrations
instrument panels
interiors
LCD displays
North American Rockwell
outer space
Space Shuttle orbiters
symmetry
vignetting
white
