New 737 Flight Deck with Heads Up Display (HUD) and Minus Eyebrow Windows

In January of 2005, Boeing rolled out its first 737 without eyebrow windows, the four small windows above the front windshield. In the past the eyebrow windows helped provide better crew visibility, but today's advanced navigation systems have made those windows obsolete. The design change reduces airplane weight by 20 pounds and eliminates approximately 300 hours of periodic inspections per airplane. Retrofit kits to cover eyebrow windows will be available mid-2006 for the in-service 737 fleet. The Heads Up Display (HUD) enhances safety and minimizes delays by providing eye-level flight and safety information to the flight crew. HUD provides the capability to takeoff and land when visibility is low.
 Add to lightbox
 Add to cart
Unique identifier BI228541
Boeing ID k63473
Type Image
Size 6035px × 4664px   80MB
License type RM
