P-12B Cockpit Lining Model

Early in 1928, Boeing built two new fighter biplanes using bolted aluminum tubing for the fuselage's inside structure, rather than welded steel tubing, typical of earlier models. Later versions had aluminum covering the fuselage rather than fabric or wood. Model 83, designed for the Navy, had a hook-type arrester so that it could land on aircraft carriers. Its production version was designated F4B. The Model 89, built for the Army as the P-12, had a rack that could hold a 500-pound bomb.
 Add to lightbox
 Add to cart
Unique identifier BI229775
Boeing ID 3755b
Type Image
Size 2898px × 2298px   6MB
License type RM
Keywords
1920s
airplanes
biplanes
close-ups
cockpits
control systems
day
detail views
fighters
glare
ground shots
historic production status
instrument panels
interiors
left rear views
manufacturing
military
nobody
photos
propeller planes
scanned from film negative
text
viewed from above
vintage / retro
