XF8B-1 Fighter Mockup Showing Folded Wing

The XF8B-1 fighter-bomber was the heaviest carrier-based airplane built before the end of World War II. The XF8B-1 could be flown as a torpedo bomber and, because of its single-seat configuration, could also be used as a fighter. Because of its size and great horsepower, the XF8B-1 used an unusual dual six-blade contrarotating propeller. It carried bombs internally and extra fuel externally, and its six machine guns were mounted inside the folding wings. Only three XF8B-1s were built. The aircraft never went into major production because changing wartime strategy required that Boeing concentrate on building land-based large bombers and transports.
 Add to lightbox
 Add to cart
Unique identifier BI220513
Boeing ID 42154b
Type Image
Size 5208px × 4112px   20MB
