Quiet Technology Demonstrator 2 Nacelle
The QTD2 is a 777-300ER modified to include azimuthally varying chevrons (AVC) designed to reduce jet engine noise. Variable chevrons are saw-toothed-shaped devices at the engine exhaust streams.
