F4B-2 Right Side Gun Installation

Early in 1928, Boeing built two new fighter biplanes using bolted aluminum tubing for the fuselage's inside structure, rather than welded steel tubing, typical of earlier models. Later versions had aluminum covering the fuselage rather than fabric or wood. Model 83, designed for the Navy, had a hook-type arrester so that it could land on aircraft carriers. Its production version was designated F4B. The Model 89, built for the Army as the P-12, had a rack that could hold a 500-pound bomb.
 Add to lightbox
 Add to cart
Unique identifier BI229787
Boeing ID 4239b
Type Image
Size 2904px × 2280px   6MB
