F-15 Pilot Wearing JHMCS Helmet
The Boeing Joint Helmet Mounted Cueing System (JHMCS) combines a magnetic head tracker with a display projected onto the pilot's visor, giving the pilot a targeting device that can be used to aim sensors and weapons wherever the pilot is looking. With JHMCS, the pilot can aim the radar, air-to-air missiles, infrared sensors and air-to-ground weapons merely by observing the target through the helmet's visor and pressing a switch on the flight controls. Additionally, the pilot can view any desired data (airspeed, altitude, target range, etc.) while "heads-up," eliminating the need to look into the cockpit during visual air combat.
Add to lightbox
Add to cart
Unique identifier
BI43843
Boeing ID
msf12-0039-066
Type
Size
2832px × 4256px 34MB
License type
RM
Keywords
2010s
adults
Boeing
close-ups
cockpits
copy space
currently in production
day
exteriors
gray
ground shots
high-tech / advanced
Joint Helmet Mounted Cueing System (JHMCS)
left side views
military livery
pilots
reflections
