Boeing F-15 Silent Eagle Wind Tunnel Model
Boeing completed wind tunnel tests on the Silent Eagle Conformal Weapons Bay (CWB) in 2012. The Silent Eagle is designed with advanced technologies that provide an unprecedented balance of survivability and lethality to meet warfighters' needs in all phases of air combat. The CWBs can be reconfigured to Conformal Fuel Tanks (CFTs) to optimize the aircraft for longer ranges and increased weapons loading, making the Silent Eagle a flexible platform with unmatched range, speed, payload and persistence. The reconfigurable CWB-CFT concept is unique in the fighter aircraft world and contributes to the overall RCS reduction package while the aircraft maintains both air-to-air and air-to-surface capabilities.
Add to lightbox
Add to cart
Unique identifier
BI233278
Boeing ID
msf12-0040-044
Type
Size
3000px × 1996px 17MB
License type
RM
Keywords
2010s
ammunition/weapons systems
blue
close-ups
Conformal Weapons Bay (CWB)
copy space
glare
head on views
high-tech / advanced
interiors
perspective lines
photos
symmetry
testing
wind tunnels
