Boeing 777-300ER Refused Takeoff Flight Test

The Boeing 777-300ER (Extended Range) completed refused takeoff testing at Edwards Air Force Base, California. A refused takeoff is where the pilot prepares for a takeoff, but then uses maximum brake energy to stop the fully-loaded airplane - 775,000 pounds (351,534 kilograms) for these tests. Because the tests measure braking performance, thrust reversers are not used. The brakes become hot and glow due to the amount of energy they absorb during the tests. Often during these types of tests small fires can occur due to the hot brakes, but no fires occurred during the 777-300ER tests. Certification tests were completed using 100 percent of maximum brake energy with fully worn brakes. Two different 777-300ER brake systems - manufactured by Goodrich and Messier-Bugatti - were certified successfully.
 Add to lightbox
 Add to cart
Unique identifier BI215526
Boeing ID k62735-32
Type Image
Size 3296px × 2528px   23MB
License type RM
Keywords
2000s
blue
close-ups
commercial passenger planes
day
engines
exteriors
gray
ground shots
jets
left front views
main wheels
nacelles
nobody
photos
red
runways
sunshine
tarmac
taxiing
testing
tilt views
tricycle landing gears
wheels
white
yellow
