Ares I Crew Launch Vehicle Jettisons Escape Tower

The escape tower is shown here being jettisoned from the Ares I upper stage in this artists conception. Boeing is competing to produce the upper stage for the Ares I crew launch vehicle, NASAs first new human-rated launch vehicle since the space shuttle. The 309-foot long, two-stage Ares I rocket is capable of launching approximately 25 metric tons into low Earth orbit. The Ares I rocket is slated for its first flight in 2009.
 Add to lightbox
 Add to cart
Unique identifier BI222507
Boeing ID msf07-1728-1
Type Image
Size 3000px × 2201px   18MB
License type RM
