TTBW.tif

On January 8, 2019, Boeing revealed the newest Transonic Truss-Braced Wing (TTBW), which researchers say will fly higher and faster than the previous TTBW concepts. The new configuration is designed to offer unprecedented aerodynamic efficiency while flying at Mach 0.80, which is consistent with the speed of many of today's jetliners. The new design is on display with other experimental aircraft concepts at the American Institute of Aeronautics and Astronautics SciTech Forum in San Diego.
 Add to lightbox
 Add to cart
Unique identifier BI414436
Boeing ID TTBW
Type Image
Size 6000px × 3472px   59MB
License type RM
